TPWK Disc-Type Tailing Reclaimer

It is mainly used for the separation of fine-grained strong magnetic ore and removing magnetic mix-in from non-magnetic slurry materials. Applicable for the iron-separation plants in connection with materials in large volume, with fine granularity and low grade or for recycling strong magnetic ore substance from the tailings of the calcination process or from the iron containing dust slime of the steel-making plants. When used for iron ore tailings re-selection, if the grade of the ore tailings is about 9%, the grade of the concentrate produced using this produce and after corresponding ore processing techniques can reach between 60% – 65%.

Note: the number of disks of the above-mentioned recollection machine can be adjusted according to the flow volume

Contact Download
Main Feature
  • 1.It is mainly used for the separation of fine-grained strong magnetic ore and removing magnetic mix-in from non-magnetic slurry materials.
  • 2.Applicable for the iron-separation plants in connection with materials in large volume,
  • 3.Aplicable to fine granularity and low grade or for recycling strong magnetic ore substance from the tailings of the calcination process or from the iron containing dust slime of the steel-making plants.
  • 4.When used for iron ore tailings re-selection, if the grade of the ore tailings is about 9%, the grade of the concentrate produced using this produce and after corresponding ore processing techniques can reach between 60% – 65%.
Technical Specification
 Model  Roller length (mm)  Working area (m2) Power/Kw Number of Magnetic Poles  Magnetic intensity on the roller surface(mT) Processing capacity
TPWK-8008 800 12 5. 5 8 150 200
TPWK-1008 1000 15 5. 5 8 150 240
TPWK-1508 1500 20 5. 5 8 150 280
TPWK-1510 1500 25 5. 5 10 150 350
TPWK-1512 1500 30 5. 5 12 150 420
TPWK-1608 1600 24 5. 5 8 150 340
TPWK-1610 1600 30 5, 5 10 150 420
TPWK-1612 1600 36 5. 5 12 150 500

Note: All the technical data as listed above is for reference only.
